New MbpStat.Net, Mbx.Net Gateway and Enron Modbus Protocol Support!
Version 9 includes new product features and additional operating system support.
New MbpStat.Net and Mbx.Net Gateway available in Mbx.Net Suite and Mbx.Net Premier Suite.
All Cyberlogic products come in both 32-bit and 64-bit editions,
and support the following operating systems:
- Windows 11
- Windows 10
- Windows 8
- Windows 7 SP1
- Windows Server 2022
- Windows Server 2019
- Windows Server 2016
- Windows Server 2012
- Windows Server 2008 R2 SP1
New Feature: MbpStat.Net
The Mbx.Net Suite and
Mbx.Net Premier Suite
include the new MbpStat.Net Modbus Plus network diagnostic utility.
The MbpStat.Net provides the same functionality as the original DOS
based MBPSTAT application. It can monitor local or remote Modbus Plus
by connecting to systems running the Mbx.Net Server. It can run on 32-bit
and 64-bit Windows, and does not require the Virtual MBX driver.
New Feature: Mbx.Net Gateway Driver
The Mbx.Net Suite and Mbx.Net Premier Suite
include the new Mbx.Net Gateway Driver.
The Mbx.Net Gateway Driver provides similar functionality to the MBX
Gateway Driver. However, the Mbx.Net Gateway Driver uses newer and more
secure infrastructure, and allows for more communication protocols.
The driver connects existing applications that use the MBXAPI, MBXAPI.Net
or NETLIB to the Mbx.Net Server. The server can be on the local network or
anywhere on the Internet. The Mbx.Net Gateway node provides access to all
MBX devices as though they were on the local system. The connection can be
through Http, Net.Tcp or Net.Pipe protocols. A secure connection can be
established and protected by a user name/password.
The Mbx.Net Gateway Driver is compatible with all other components of the MBX family.
New Feature: OPC Server supports Modbus extensions including the Enron Modbus protocol
User defined address maps can describe the memory layout of custom Modbus devices.
The MBX OPC Server Suite supports
devices that use standard Modbus as well as the Modbus extensions. To accommodate the
variety of existing devices, the server allows the user to describe the internal data memory
layout by setting up an address map for each device type. 32-bit and 64-bit data registers
are now supported.
Data Logger
The DHX OPC Enterprise Suite, MBX OPC Enterprise Suite, OPC
Crosslink Enterprise Suite, OPC Datacenter Suite, and OPC Datacenter
Premier Suite products
include the new Data Logger feature:
The Data Logger gives the Cyberlogic OPC Server the capability to log
real-time data to a database for archiving, later analysis, and other
purposes.
Logging data at the server reduces complexity and cost compared to
client-based logging options. In addition, the OPC server can expose the
internal status and diagnostic information of the logging operations as
OPC data items which OPC clients can use to monitor and control the
logging process.
Cyberlogic's Data Logger includes many advanced features, some of which
are unique to Cyberlogic. Here are just a few of them:
- Supports MS SQL Server, MS Access, Oracle, and MySQL databases.
- Simultaneously log to multiple databases, which may be of different
types.
- Supports local and remote database connections.
- New records can be generated at a fixed interval, on data change,
when triggered by a data item, or a combination of all these methods.
- Extensive set of standard trigger events that can be used to
initiate logging.
- Custom trigger events can be programmed using Math & Logic.
- Memory and disk cache to store data records if the database
connection is slow or unavailable.
Triggers and Switches
All Cyberlogic OPC products include
the new pre-programmed Math & Logic Triggers and Switches:
Triggers and Switches are pre-programmed Math & Logic applets that
are used to detect and flag user-specified conditions. These applets
require no programming knowledge. They are configured using dialogs.
Triggers are counters that increment whenever a time-based event
occurs, such as a specific time of day, a specific interval passes, etc.
Four trigger types currently exist: Daily, Weekly, Monthly, and
Interval.
Switches test the state of items and signal true or false based on that
state. Current switch types are Comparison, Duration, Quality, and
Shift.
PCIe-85 (416NHM30042A) Modbus Plus Adapter Support
Beginning with version 8.1, all Cyberlogic MBX Family products
(MBX Driver Suite, MBX OPC Server Suite, MBX OPC Premier Suite, MBX OPC Enterprise Suite,
and MBX Bridge Suite) include support for the PCIe-85 (416NHM30042A) Modbus Plus
adapter.
The Schneider Electric PCIe-85 (416NHM30042A)
adapter card replaces the legacy PCI-85 single-channel (416NHM30030) and PCI-85 dual-channel
(416NHM30032) adapters. The PCIe-85 can be configured to either single-channel or
dual-channel operation. The adapter supports the PCI Express (PCIe) bus, which
replaced the legacy PCI bus. The new adapter provides better performance, is fully
compatible with the original PCI-85 adapter, and requires a single lane (x1)
full height PCIe slot.
Unsure of whether to use the USB TSXCUSBMBP or the PCIe-85 adapter for your application?
Read this for help.
OPC Datacenter Suite
OPC Data Logger
OPC Datacenter Suite adds data logging capabilities to any
Cyberlogic OPC product:
- Supports MS SQL Server, MS Access, Oracle, and MySQL databases.
- Simultaneously log to multiple databases, which may be of
different types.
- Supports local and remote database connections.
- New records can be generated at a fixed interval, on data
change, when triggered by a data item, or a combination of all
these methods.
- Pre-programmed Math & Logic Triggers and Switches.
- Memory and disk cache to store data records if the database
connection is slow or unavailable.
> Read full product details of OPC Datacenter Suite
Back to Top
OPC Datacenter Premier Suite
OPC Data Logger with OPC Math & Logic
Get all the features of the OPC Datacenter Suite and the powerful
data-manipulation capabilities of Math & Logic in one integrated
package:
It retains all of the OPC Datacenter Suite capabilities, allowing
data to be logged to multiple databases simultaneously. Now, users
can program complex mathematical and logical manipulations of data
as it passes through:
- Supports MS SQL Server, MS Access, Oracle, and MySQL databases.
- Simultaneously log to multiple databases, which may be of
different types.
- Supports local and remote database connections.
- New records can be generated at a fixed interval, on data
change, when triggered by a data item, or a combination of all
these methods.
- Pre-programmed Math & Logic Triggers and Switches.
- Custom trigger events can be programmed using Math & Logic.
- Memory and disk cache to store data records if the database
connection is slow or unavailable.
- Program math and logic expressions to convert, control and
manipulate data.
> Read full product details of OPC Datacenter
Premier Suite
Back to Top
OPC Crosslink Suite
OPC Data Bridge, OPC Data Concentrator and Redundant OPC Server
Hub
OPC Crosslink Suite allows the user to pass data between any
combination of OPC DA servers and PLCs, and it enables the user to
set up the following OPC configurations:
- Redundant OPC servers with an unlimited number of backup
servers.
- OPC data bridges that pass data from one OPC server to another,
from one PLC to another, or between OPC servers and PLCs. The
source and target systems may be any combination of OPC DA servers
and PLCs, even from different vendors.
- OPC data concentrators that obtain data from other OPC DA
servers—regardless of brand or spec level—and present it to OPC
clients. Because Cyberlogic’s OPC servers comply with OPC DA 3.0,
2.05a and 1.0a specifications, this concentrator configuration
will solve spec level mismatches that may exist between some
clients and servers.
> Read full product details of OPC Crosslink Suite
Back to Top
OPC Crosslink Premier Suite
OPC Math & Logic, OPC Data Bridge, OPC Data Concentrator and
Redundant OPC Server Hub
This powerful new product adds Math & Logic to the OPC
Crosslink Suite.
It retains all of the OPC Crosslink Suite capabilities, allowing
the user to pass data between any combination of OPC DA servers and
PLCs. Now, users can program complex mathematical and logical
manipulations of data as it passes through:
- Redundant OPC servers with an unlimited number of backup
servers.
- OPC data bridges that pass data from one OPC server to another,
from one PLC to another, or between OPC servers and PLCs. The
source and target systems may be any combination of OPC DA servers
and PLCs, even if they are of different families or are from
different vendors.
- OPC data concentrators that obtain data from other OPC DA
servers—regardless of brand or spec level—and present it to OPC
clients. Because Cyberlogic’s OPC servers comply with OPC DA 3.0,
2.05a and 1.0a specifications, this concentrator configuration
will solve spec level mismatches that may exist between some
clients and servers.
- Pre-programmed Math & Logic Triggers and Switches.
- Program math and logic expressions to convert, control and
manipulate data.
> Read full product details of OPC Crosslink
Premier Suite
Back to Top
OPC Crosslink Enterprise Suite
OPC Data Logger, OPC Math & Logic, OPC Data Bridge, OPC Data
Concentrator and Redundant OPC Server Hub
This powerful new product adds the OPC Data Logger to the OPC
Crosslink Premier Suite.
It retains all of the OPC Crosslink Premier Suite capabilities,
such as allowing data to pass between any combination of OPC DA
servers and PLCs and allowing data manipulation through custom
programs. It adds the ability to log data to relational databases.
- Bridge Data between OPC Servers.
- Bridge Data between PLCs.
- Bridge Data between OPC Servers and PLCs.
- Configure an OPC Data Concentrator.
- Configure Redundant OPC Servers.
- Configure Redundant PLCs.
- Configure Redundant Networks.
- Program math and logic expressions to convert, control and
manipulate data.
- Supports MS SQL Server, MS Access, Oracle, and MySQL databases.
- Simultaneously log to multiple databases, which may be of
different types.
- Supports local and remote database connections.
- New records can be generated at a fixed interval, on data
change, when triggered by a data item, or a combination of all
these methods.
- Pre-programmed Math & Logic Triggers and Switches.
- Custom trigger events can be programmed using Math & Logic.
- Memory and disk cache to store data records if the database
connection is slow or unavailable.
> Read full product details of OPC
Crosslink Enterprise Suite
Back to Top
MBX Driver Suite
Industry Standard Communication Drivers for Modbus, Modbus Plus
and Modbus/TCP Networks
The OEM edition of the MBX Driver Suite (part number SWMXDS001) is distributed by Schneider Electric, and it
is the worldwide standard for communication drivers for Modbus,
Modbus Plus and Modbus/TCP networks.
The suite includes:
- MBX Driver for all Modicon Modbus Plus network adapters.
- MBX Gateway Driver for remote access to all Modicon networks.
- Ethernet MBX Driver for Modbus TCP/IP communications.
- Serial MBX Driver for Modbus communications.
- Virtual MBX Driver for enabling 16-bit legacy applications in
32-bit Windows.
> Read full product details of MBX Driver Suite
Back to Top
MBX OPC Server Suite
Compliance-Certified OPC Server Suite for Modicon Networks and
Devices
The all-in-one MBX OPC Server Suite includes Cyberlogic OPC server
and all device drivers for all Modicon networks, PLCs and interface
cards.
The suite includes:
- Cyberlogic OPC Server.
- Pre-programmed Math & Logic Triggers and Switches.
- MBX Driver for all Modicon Modbus Plus network adapters.
- MBX Gateway Driver for remote access to all Modicon networks.
- Ethernet MBX Driver for Modbus TCP/IP communications.
- Serial MBX Driver for Modbus communications.
- Virtual MBX Driver for enabling 16-bit legacy applications in
32-bit Windows.
> Read full product details of MBX OPC Server Suite
Back to Top
MBX OPC Premier Suite
MBX OPC Server Suite with OPC Math & Logic.
Get all the features of the MBX OPC Server Suite and the powerful
data-manipulation capabilities of Math & Logic in one integrated
package:
- OPC Server for Modicon Modbus, Modbus Plus and Modbus/TCP
networks and devices.
- Pre-programmed Math & Logic Triggers and Switches.
- Program math and logic expressions to convert, control and
manipulate data.
> Read full product details of MBX OPC Premier Suite
Back to Top
MBX OPC Enterprise Suite
MBX OPC Server Suite with OPC Data Logger, OPC Math & Logic,
OPC Data Bridge, OPC Data Concentrator and Redundant OPC Server Hub
Get all the features of the MBX OPC Server Suite, the OPC
Crosslink Premier Suite, and the OPC Datacenter Suite in one
integrated package:
- OPC Server for Modicon Modbus, Modbus Plus and Modbus/TCP
networks and devices.
- Program math and logic expressions to convert, control and
manipulate data.
- Bridge Data between OPC Servers.
- Bridge Data between PLCs.
- Bridge Data between OPC Servers and PLCs.
- Configure an OPC Data Concentrator.
- Configure Redundant OPC Servers.
- Configure Redundant PLCs.
- Configure Redundant Networks.
- Supports MS SQL Server, MS Access, Oracle, and MySQL databases.
- Simultaneously log to multiple databases, which may be of
different types.
- Supports local and remote database connections.
- New records can be generated at a fixed interval, on data
change, when triggered by a data item, or a combination of all
these methods.
- Pre-programmed Math & Logic Triggers and Switches.
- Custom trigger events can be programmed using Math & Logic.
- Memory and disk cache to store data records if the database
connection is slow or unavailable.
> Read full product details of MBX OPC Enterprise
Suite
Back to Top
MBX Bridge Suite
PC-Based Router/Bridge for Devices on Modbus, Modbus Plus and
Modbus/TCP Networks
The MBX Bridge Suite combines the functionality of all
hardware-based bridging products currently offered by Schneider
Electric for Modbus, Modbus Plus and Modbus/TCP networks.
This is the same software that powers Schneider Electric’s
174CEV20040 Modbus Plus to Ethernet Bridge hardware.
The suite includes:
- MBX Bridge.
- MBX Driver for all Modicon Modbus Plus network adapters.
- MBX Gateway Driver for remote access to all Modicon networks.
- Ethernet MBX Driver for Modbus TCP/IP communications.
- Serial MBX Driver for Modbus communications.
- Virtual MBX Driver for enabling 16-bit legacy applications in
32-bit Windows.
> Read full product details of MBX Bridge Suite
Back to Top
Mbx.Net Suite / Mbx.Net Premier Suite
NEW! MbpStat.Net, Mbx.Net Gateway and Mbx.Net Server
These new suites can work with any version of the MBX products, as long as they are installed on the
supported Windows platforms.
These products introduce the new Cyberlogic Mbx.Net architecture.
This architecture provides secure and reliable remote connectivity
infrastructure for the Cyberlogic MBX family of products. It is also
a platform for the Mbx.Net applications, such as the MbpStat.Net and the Mbx.Net Gateway Driver.
> Read full product details of Mbx.Net Suite/Mbx.Net Premier Suite
Back to Top
MBX SDK
Software Development Kit for Application Developers
API for connectivity to Modbus, Modbus Plus and Modbus/TCP
networks and devices.
The suite includes:
- MBX SDK
- MBX OPC Premier Suite (includes all drivers, MBX OPC Server, and
Math & Logic)
> Read full product details of MBX SDK
Back to Top
DHX Driver Suite
Communication Drivers for Allen-Bradley Networks and Devices
Communication drivers for all popular Allen-Bradley and SST DH,
DH+, DH-485 and ControlNet network adapters.
The suite includes:
- DHX Driver for all popular Allen-Bradley and SST DH, DH+, DH-485
and ControlNet network adapters.
- DHX Gateway Driver for remote access to all Allen-Bradley
networks.
- ControlLogix Gateway Driver for remote access to Allen-Bradley
DH+ through DHRIO.
- Ethernet DHX Driver for Allen-Bradley Ethernet communications.
- Serial DHX Driver for DF-1 communications.
- Virtual DHX Driver for enabling 16-bit legacy applications in
32-bit Windows.
> Read full product details of DHX Driver Suite
Back to Top
DHX OPC Server Suite
Compliance-Certified OPC Server Suite for Allen-Bradley Networks
and Devices
The all-in-one DHX OPC Server Suite includes Cyberlogic OPC server
and all device drivers for Allen-Bradley networks, PLCs and
interface cards.
The suite includes:
- Cyberlogic OPC Server
- Pre-programmed Math & Logic Triggers and Switches.
- DHX Driver for all popular Allen-Bradley and SST DH, DH+, DH-485
and ControlNet network adapters.
- DHX Gateway Driver for remote access to all Allen-Bradley
networks.
- ControlLogix Gateway Driver for remote access to Allen-Bradley
DH+ through DHRIO.
- Ethernet DHX Driver for Allen-Bradley Ethernet communications.
- Serial DHX Driver for DF-1 communications.
- Virtual DHX Driver for enabling 16-bit legacy applications in
32-bit Windows.
> Read full product details of DHX OPC Server Suite
Back to Top
DHX OPC Premier Suite
DHX OPC Server Suite with OPC Math & Logic.
Get all the features of the DHX OPC Server Suite and the powerful
data-manipulation capabilities of Math & Logic in one integrated
package:
- OPC Server for Allen-Bradley DH, DH+, DH-485, ControlNet, A-B
Ethernet, ControlLogix, ControlLogix Gateway and DF1 networks and
devices.
- Pre-programmed Math & Logic Triggers and Switches.
- Program math and logic expressions to convert, control and
manipulate data.
> Read full product details of DHX OPC Premier Suite
Back to Top
DHX OPC Enterprise Suite
DHX OPC Server Suite with OPC Math & Logic.
Get all the features of the DHX OPC Server Suite, the OPC
Crosslink Premier Suite, and the OPC Datacenter Suite in one
integrated package:
- OPC Server for Allen-Bradley DH, DH+, DH-485, ControlNet, A-B
Ethernet, ControlLogix, ControlLogix Gateway and DF1 networks and
devices.
- Program math and logic expressions to convert, control and
manipulate data.
- Bridge Data between OPC Servers.
- Bridge Data between PLCs.
- Bridge Data between OPC Servers and PLCs.
- Configure an OPC Data Concentrator.
- Configure Redundant OPC Servers.
- Configure Redundant PLCs.
- Configure Redundant Networks.
- Supports MS SQL Server, MS Access, Oracle, and MySQL databases.
- Simultaneously log to multiple databases, which may be of
different types.
- Supports local and remote database connections.
- New records can be generated at a fixed interval, on data
change, when triggered by a data item, or a combination of all
these methods.
- Pre-programmed Math & Logic Triggers and Switches.
- Custom trigger events can be programmed using Math & Logic.
- Memory and disk cache to store data records if the database
connection is slow or unavailable.
> Read full product details of DHX OPC Enterprise
Suite
Back to Top
DHX SDK
Software Development Kit for Application Developers
API for connectivity to Allen-Bradley networks and devices.
The suite includes:
- DHX SDK
- DHX OPC Premier Suite (includes all drivers, DHX OPC Server, and
Math & Logic)
> Read full product details of DHX SDK
Back to Top
Cyberlogic Developer Network
Join the Cyberlogic Developer Network!
The Cyberlogic Developer Network is designed to allow Cyberlogic
customers to use Cyberlogic’s OPC software products under free
development licenses.
Who is eligible to sign-up for this program?
Professional systems integrators, in-house automation engineers and
IT departments of the end-user companies are eligible to join the
Cyberlogic Developer Network.
Are these full products?
Yes. The developers who sign up for the program will receive a
media kit for the retail versions of the products. The software can
also be downloaded from the Cyberlogic website and used with the
Developer Network activation keys.
Are there any restrictions to use the developer licenses?
Yes. The development licenses are solely for use in systems
development, integration and testing. The development licenses are
not intended for production and they are not allowed to be used as
"runtime" licenses.
> Read full product details of Cyberlogic DevNet
Back to Top
Compliance-Certified OPC
Cyberlogic OPC Products are "Certified for Compliance" by the OPC
Foundation
The OPC Foundation established an OPC Certification Program, where
the “Certified” level of testing is provided by independent, OPC
Foundation-sanctioned test labs.
Cyberlogic was the first company to submit its OPC products to the
independent certification test lab, Ascolab GmbH (Erlangen,
Germany), for a range of tests that cover compliance and
interoperability testing, load and performance testing, stress
testing, white box testing, behavior testing, and environment and
usability testing. Products are awarded the “Compliance Certified”
status when all interfaces they support have passed all of the
independent lab tests.
The OPC Foundation website
recommends that “OPC Users should look for OPC Client and OPC Server
products that have passed ‘Compliance Certification’ Testing and
display the ‘Certified’ logo”.
Cyberlogic became the first company to receive the OPC Foundation’s
valuable "Certified" status in 2008, and the company's OPC Suites
are the first OPC products
authorized to carry the OPC Foundation's valuable "Certified" logo.
All Cyberlogic OPC products support:
- OPC Data Access 3.0, 2.05a and 1.0a
- OPC Alarms & Events 1.1
- OPC XML Data Access 1.0
Back to Top
